Fluoro Elastomer Rubber Sheeting

Fluoro Elastomer Rubber Sheeting

Fluoroelastomer or FKM is a class of synthetic rubber designed for very high temperature operation. FKM is highly recommended for most solvents, Hydrocarbons, aliphatic, aromatic and chlorinated chemicals, resistance to acids and alkalis including oxidants, high temperature stability, excellent sealing properties, low compression set and resistance to aging. FKM rubber sheet is widely used as gaskets, O-rings, seals, fuel system components, Lining in various industries like Automotive, Oil& Gas, defence, Heavy Machinery, Aerospace etc The polymer has high resistance to heat with a temperature range of -40° C to + 250° C.
Zenith is an official distributor of Chemours Genuine Viton.

Fluoro Elastomer Rubber Sheeting
Code Colour Specific Gravity Hardness (±5) Tensile Strength Elongation Finish Type TDS
Gm/cm3 SHORE A Kg/cm2(min) % (min)
VI 70190 Black 1.95 ± 0.05 75 50 200 Smooth/Fabric -
Standard Length 10 Mtr 33 Ft 11 Yard
Standard Width 1.2/1.4/1.5/2 Mtr 4/4.6/4.92/6.56 Ft 1.33/1.53/1.64/2.18 Yard
Note
  1. Sheets can be supplied with 1 or 2 ply insertion/s in Cotton, Nylon, Polyester, Glass Fibre etc.
  2. One side or both side smooth or fabric finish can be supplied.
  3. Specifications are subject to change without notice.
